SND830 Synthetic Diamond Powder for General Purpose Cutting and Grinding

short description:

SND830 Synthetic Diamond Powder for Heavy Impact Loading Synthetic Industrial Diamond Powder 2. SND830 Diamond Powder Character Low to Medium toughness, semi-blocky shape, low to medium transparency and impact resistance, low thermal stability. Applied for for making diamond blade or girnding wheels for general application. 3. Saw Grit Synthetic Diamond Powder Avaliable Size 20/25 25/30 30/35 35/40 40/45 45/50 50/60 60/70 70/80 SND820 √ √ √ √ √ √ √ √ ...

Send email to us

Product Detail

Product Tags

SND830 Synthetic Diamond Powder for Heavy Impact Loading

Synthetic Industrial Diamond Powder

2. SND830 Diamond Powder Character

Low to Medium toughness, semi-blocky shape, low to medium transparency and impact resistance, low thermal stability. Applied for for making diamond blade or girnding wheels for general application.

3. Saw Grit Synthetic Diamond Powder Avaliable Size

	20/25	25/30	30/35	35/40	40/45	45/50	50/60	60/70	70/80
SND820	√	√	√	√	√	√	√	√	√
SND830	√	√	√	√	√	√	√	√	√
SND840	x	x	√	√	√	√	√	√	√
SND860	√	√	√	√	√	√	√	√	√
SND870	x	x	√	√	√	√	√	√	√
SND880	√	√	√	√	√	√	√	√	√
SND890	√	√	√	√	√	√	x	x	x

4. Other Grade and Mesh Size Diamond

SND-G05	50/60-325/400	Light green color, irregular shape with lower toughness. Widely used for processing stones, concretes, ceramics, etc.
SND-G10	30/35-325/400	Yellow color, irregular shape with a standard hardness, Applied in ceramic bonded, resin bonded and all kinds of electroplating products, for processing stones, hard alloy, magnetic materials, natural diamond, gem.
SND-G15	30/35-325/400	Yellow color, high hardness and toughness. Applied in ceramic bond,resin bond and all kinds of electroplating products, can be used for heavy duty processing on carbide, glass, ceramics, stone and other non-metallic materials.
SND-G20	80/100-325/400	Mix of regular and angular crystals, medium-low toughness with blocky shaped crystals. It is suitable for the application of high efficiency diamond tools.
SND-G30	80/100-325/400	Medium touhness with a better diamond shpe. Suitable for the diamond tools of beveling glass or crystal, grinding of carbide and magnetic materials, etc.
SND-G40	80/100-325/400	Medium high toughness with regular shape, good high thermal stability and impact resistance. Applied to make grinding & abrasives wheels to process medium load materials, like core drilling of glass, pencil edging, and engraving decorative glass and crystal.
SND-G60	80/100-325/400	Certain of cubooctahedral shape, high impact strength and thermal stability. Applied in the condition requiring high grinding rate, like electroplated tools to grind and polish stones, ceramics, glasses, and magnetic materials, etc.
